LNG Storage Tanks

Model

Specification

Model selection

Suitable for single (double) pumps single machine (tank)

MUBP40-A MUBP40-B

Inlet pressure : 0.02〜0.8 MPa   Outlet pressure: 1.6、2.5、5.0 MPa  Liquid fiow : 6m3/h   Power Supply : 380V、3 Phase、50Hz   Power:7.5kW、11kW、18.5kW

Single pump Double pumps(One use One backup )

Suitable for single (double) pumps double machines (tanks)

MUBP80-AMUBP80-B

Inlet pressure : 0.02〜0.8 mpa Outlet pressure: 1.6、2.5、5.0 mpa Liquid ilow : 12m3/h Power supply : 380v、3 phase 、50hz Power: 11kw、18.5kw,37kw、

Single pump Double pumps(One use One backup )

Suitable for single (double) pumps Quadra machines (tanks)

MUBP120-AMUBP120-B

Inlet Pressure : 0.02〜0.8 Mpa Outlet pressure : 1.6、2.5 MPa Liquid ilow : 24m3/h flower Supply : 380V、3 Phase 、50Hz Power : 22kW、37kW

Single pump Double pumps(One use One backup )

Suitable for single (double) pumps Eight machines (tanks)

MUBP160-AMUBP160-B

Inlet pressure : 0.02〜0.8 MPa Outlet pressure : 1.6 MPa Liquid ilow : 36m3/h flower Supply : 380V、3 Phase 、50Hz Power: 37kW

Single pump Double pumps(One use One backup )

 Standard configuration  Optional configuration

 LNG liquid pump, EAG release system, liquid filling system and PLC automatic control system.  Tanker pressurization system, cryogenic hose, instrument system, computer electrical monitoring system, liquid metering system
