Product Overview

CRYO-TECH's Air Separation Unit (ASU) is a modular, energy-efficient solution designed to produce high-purity oxygen, nitrogen, argon, and rare gases for industrial applications. Leveraging advanced cryogenic distillation and adsorption technologies, our ASUs deliver reliable gas supply while minimizing operational costs.

Key Features

Low-Pressure Process: Reduces energy consumption by 20% compared to conventional designs.
Modular Design: Customizable configurations for capacities ranging from 200 Nm³/h to 10,000 Nm³/h.
HSEQ Compliance: Meets ISO 9001, ISO 14001, and OHSAS 18001 standards for safety and environmental responsibility.
Advanced Control System: PLC-based automation with real-time monitoring and remote diagnostics.
Long-Term Reliability: 99.5% uptime guaranteed through robust component selection and redundant systems.

Technical Specifications

Gas Purity	99.5% – 99.999% (O₂ / N₂ / Ar)
Pressure Range	0.8 – 1.6 MPa (gaseous)
Liquid Storage Capacity	5 – 50 m³ (optional)
Power Consumption	≤0.65 kWh/Nm³ (O₂)
Noise Level	<85 dB(A)

Liquid Air Separation Unit — Model Specifications

Liquid Air Separation Unit
		KDON-200Y/200Y	KDON-500Y/500Y	KDON-1000Y/1000Y	KDON-1500Y/1500Y	KDON-2000Y/2000Y	KDON-3000Y/3000Y	KDON-4500Y/2000Y
MODEL		KDON-200Y/200Y	KDON-500Y/500Y	KDON-1000Y/1000Y	KDON-1500Y/1500Y	KDON-2000Y/2000Y	KDON-3000Y/3000Y	KDON-4500Y/2000Y
LOX Capacity	Nm³/h	200	500	1000	1500	2000	3000	4500
LOX Purity	%	99.6	99.6	99.6	99.6	99.6	99.6	99.6
LIN Capacity	Nm³/h	200	500	1000	1500	2000	3000	2000
LIN Purity	%(N2)	99.999	99.999	99.999	99.999	99.999	99.999	99.999
LAr Capacity	Nm³/h	-	-	25	40	55	95	145
LAr Purity	%(Ar)	-	-	99.999	99.999	99.999	99.999	99.999
Start-up Time	Hour	8~12	~20	~24	~24	~24	~24	~24
Operation Period	Year	≥1	≥1	≥2	≥2	≥2	≥2	≥2

Product Offerings

Small & Medium-Sized ASU
- Capacities: 200 – 5,000 Nm³/h
- Ideal for steel mills, chemical plants, and healthcare facilities.
Pure Nitrogen Equipment
- Purity: 99.999% (5N)
- Applications: Electronics, food packaging, and inert gas blanketing.
Pressure Swing Adsorption (PSA) Systems
- Fast startup (≤30 minutes)
- Low maintenance with minimal moving parts.
