Product Overview

CRYO-TECH's Cryogenic Mobil Tank is a versatile, high-performance solution designed for efficient transportation and on-site storage of cryogenic liquids (LN₂, LO₂, LAr, LNG, LCO₂, etc.). Combining advanced vacuum insulation technology with rugged mobility, this semi-trailer system ensures minimal evaporation loss and reliable performance for long-haul logistics, industrial distribution, and emergency supply applications.

Key Features

Heavy-Duty Construction: Reinforced frame and aerodynamic design for stability during transit and resistance to harsh road conditions.
Integrated Onboard Pressure Building Unit (PBU): Enables direct unloading without external equipment, reducing operational complexity.
Lockable Valve Enclosure: Protects critical components from damage and unauthorized access.
High-Efficiency Insulation: Vacuum multi-layer insulation (standard) or stacked insulation (for LCO₂) minimizes evaporation loss.
Safety Compliance: Pressure relief systems, emergency shut-off valves, and corrosion-resistant materials meet global safety standards.

Certifications

Pressure Vessel Standards: China GB 150 or ASME VIII DIV. 1 (user-selectable).
Quality Management: ISO 9001:2015 certified.

Technical Specifications

Design Pressure	3 – 34 bar (customizable)
Total Volume	3 m³ – 60 m³ (standard or custom)
Effective Volume	95% of total volume
Inner Tank Material	S30408 Stainless Steel
Jacket Tank Material	Q345R Low-Alloy Steel or S30408 Stainless Steel
Design Temperature	-196°C (inner) / -40°C to +50°C (outer)
Insulation	High-vacuum multi-layer (standard) / Stacked (for LCO₂)

Cryogenic transport tanks China. Designed for storage and transportation of liquid oxygen, nitrogen, argon
Capacity (m³)	Working pressure (MPa)	Dimensions (mm)	Empty weight (Kg)
2	0.25	1912×2242×3280	2650
3	0.25	1912×2242×3800	3470
5	0.25	1912×2242×5570	4720
8	0.25	2016×2225×5725	5910
10	0.25	2216×2510×6315	6310
15	0.25	2316×2741×8293	10000
25	0.25	2316×2741×12563	14525

Applications

Industrial Transportation: Welding, metal fabrication, and cryogenic process industries.
On-Site Storage: Remote locations, construction sites, and industrial complexes.
Emergency Response: Healthcare, research, and energy sectors requiring backup cryogenic supply.

CRYO-TECH Advantage

Mobility & Efficiency: Optimized weight distribution and compact design for highway transportation.
Customization: Tailored pressure ratings, capacities, and configurations to meet project needs.
Global Support: Turnkey installation, operator training, and 24/7 technical service.

CRYO-TECH's Cryogenic Mobil Tanks deliver reliable cryogenic logistics solutions for a wide range of industries.
