LNG,L-CNG Filling Station |
|
|
|
|
|||
|
Parameter |
Station Type |
Mini LNG Filling Station |
Mini L-CNG Filling Station |
||||
|
Main Technical Summary |
Daily Filling Capacity (Nm3) |
8000〜15000 |
8000 〜20000 |
|
|
|
|
|
LNG Storage Capacity (m3) |
1x60 |
1x60 |
|
|
|
|
|
|
Tank Pressure(MPa) |
1.44 |
0.88 OR1.44 |
|
|
|
|
|
|
System Pressure (MPa) |
2 |
27.5 |
|
|
|
|
|
|
Power (KW) |
15〜30 |
25〜50 |
|
|
|
|
|
|
Gas metering accuracy (％) |
1 |
0.5 |
|
|
|
|
|
|
Main Equipments |
Tank Quantity (Set) |
1〜2 |
1〜2 |
|
|
|
|
|
Dispenser (Set) |
1〜2 |
1〜2 |
|
|
|
|
|
|
Pump (Set) |
1〜2 (Immersed Pump） |
1〜2 (Plunger Pump） |
|
|
|
|
|
|
Control System |
PLC |
|
|
|
|
||
|
SIA System |
Flammable gases alarm interlock ESD protection system |
|
|
|
|
||
